EarthQuake 9800B - Manual (Page 11)

ARDISAM
Page 11
MINIMUM ORDER ...................................................................................................................... $10.00
EARTHQUAKE MODEL 9800B
PART # DESCRIPTION QTY.
8939 GEAR CASE, LOWER HALF ....................................... 1
9018 CLUTCH DRUM ........................................................... 1
9038 GEAR CASE, UPPER HALF ......................................... 1
9211 HANDLE GRIP, 7/8" ID FLANGELESS ....................... 4
9214A GEAR, 10T CLUSTER PINION HT ............................. 1
9811 SWITCH, ON/OFF (Not Shown) ................................... 1
9814 GEAR, 7T PINION THREADED ................................. 1
9816 HANDLE, 2-HOLES ...................................................... 3
9817 HANDLE, 3-HOLES ...................................................... 1
9819 MAIN HANDLEBAR ASSEMBLY .............................. 1
9825 ROTOR, CENTRIFUGAL CLUTCH COMPLETE ..... 1
9837A MOUNT RING .............................................................. 1
53627 CABLE, THROTTLE 43-1/2" ........................................ 1
63124 SPRING, THROTTLE EXTENSION ............................ 1
GC5020 GAS CAP, BRIGGS 5HP ............................................... 1
GT5HPB GAS TANK ASSEMBLY, BRIGGS 5HP ....................... 1
WK6 WOODRUFF KEY #6 .................................................... 1
PART # DESCRIPTION QTY.
60G56 LOCKNUT, BI-WAY 5/16-18 ........................................ 8
420 BOLT, C-BORE 5/16-24 X 3/4" ..................................... 4
500 GAS ENGINE, BRIGGS & STRATTON 5 HP ............. 1
503 BOLT, HEX HD 5/16-18 X 1-1/2" ................................. 4
4819 TRIGGER ASSEMBLY LONG THROW ...................... 1
8655 BOLT, HEX HD 5/16-18 X 1-3/4" ................................. 4
8906WC SCREW, PHILLIPS PAN 10-32 X 1-1/4" ....................... 1
8912 GEAR, 44T 3/4" HOLE .................................................. 1
8913 SHAFT, OUTPUT 7/8" .................................................. 1
8914 GEAR, 48T HARD ......................................................... 1
8915 DOWEL PIN, STEEL 1/4" X 1/2" .................................. 2
8919 GASKET-POWERHEAD TRANSMISSION ................ 1
8922 BEARING, BALL R12 DOUBLE LIP ........................... 3
8923 BEARING, BALL R10 ................................................... 2
8924 RING, SNAP EXTERNAL 3/4" ..................................... 3
8929 BOLT, SHCS, 1/4-20 X 1-1/2" ........................................ 2
(gear case bottom to gear case top)
8935 BOLT, SHCS 1/4-20 X 2-1/2" ......................................... 4
(gear case to handlebar plate)
WWW.ARDISAM.COM 1-800-345-6007
