Operator's Manual
CS3814, CS3816, CS4116 Chainsaws
specifications
specifications
Displacement 37.2cc (CS3814/CS3816)
40.1cc (CS4116)
Fuel Mixture (Unleaded Gasoline, 50: two-cycle oil 1)
Fuel tank capacity 310 ml
Chain oil Bar chain oil for proper season
Oil tank capacity 210 ml
Carburetor Diaphragm type
Fuel consumption at maximum engine power 560 g/kw.h
Idling speed 3000 rpm max / rpm +/- 150
Maximum speed with cutting attachment 11,000 r/min
Ignition system CDI with timing advance function
Spark Plug Champion CJ7Y or equivalent
Oil feeding system Mechanical plunger pump with adjuster
Sprocket Teeth x Pitch 6T x .375”
Dimensions (L x W x H) 710-76 x 235 x 240 mm
28” - 30” x 9.25” x 9.5”
Dry weight (without guide bar and chain,
empty tanks
9.26 lb
Guide Bar Type Sprocket Nose
Guide Bar Size 14” (CS3814)
16” (CS3816/CS4116)
Saw Chain Type Oregon® 91VG or 91P S52 (CS3814)
Oregon® 91VG or 91P S57 (CS3816/4116)
Pitch 3/8” Low Profile
Gauge .050”
Specifications are subject to change without notice.
Model 2006/42/EC Operator Ear
L
PA
(dBA)
2006/42/EC Sound Power Level
L
WA
(dBA)
2006/42/EC Hand/Arm Vibration
Max m/s 2
CS38 100 110 10.5
CS41 100 110 10.5
CS45 102 110 12.5
Sound levels tested in accordance with ISO3744 & ISO 11201 - Grade 2 (Engineering ) Method. Readings taken with engine at full throttle.
EAV = Exposure Action Value, ELV = Exposure Limit Value
sound and ViBration leVels
