Dv Mark Frank Gambale Combo 112 - Manual (Page 8)

8
Preamps: solid state (CLEAN) / tube (LEAD)
Preamp tubes (LEAD channel): 4x ECC83
Power amp: solid state
Power output: 85W @ 16 ohms; 150W @ 8 ohms;
250W @ 4 ohms
Channels:
Two
Controls:
. . . . . . . . . . Gain - Master - Presence (for each channel)
. . . . . . . . . . Riverbero (applies to both channels)
EQ controls:
Low - Mid - High (for each channel)
Speaker outputs: Two; minimum load: 4 ohms
Power Requirement:
(Voltage is factory preset according to region of sale)
100V; 120V; 230V; 240V
50/60Hz
DV Mark amps/combos are manufactured to be sold and used
in the country of purchase, and they are factory preset to that
country’s voltage. Due to homologation issues, the voltage may
not be changed.
TECHNICAL SPECS
Speaker size: 1x12” B&C Neodymium DV Mark Custom
Speaker power handling: 150W (AES standard);
impedance: 16 ohms
Dimensions:
476 x 432 x 308 mm / 20.31” x 18.15” x 10.98”
Weight: 11,7 kg / 25.79 lbs
