5
the highs need to be set a bit lower than the other channels, especially for soloing.
9) SOLO This 6 dB boost is activated by either a footswitch or the Smart Controller, and is optimized for notching up your volume for solos
during live performance. The SOLO control can only be engaged when the effects loop is active, since it’s part of the effects loop circuit.
10) STANDBY Before powering on, make sure this switch is in standby position. When you turn on the power, the microcontroller waits for
the tubes to heat up before turning on the plate voltage. The “power on” LED will flash for 30 seconds before the amp is ready. When the LED
stops blinking, flip the standby switch to the ON position. Between sets or whenever you’re on a break from playing, put the amp in standby
position (down).
11) POWER This switch delivers AC power to the amp. Make sure the unit is grounded; all three terminals of the AC power plug must be
connected to avoid any injury to the user or damage to the unit. DV Mark amps and combos are manufactured to be used in the country where
they have been sold, and are factory preset to that country’s voltage. So make sure you’re sending the correct voltage to your amp before you
connect it to AC power. Follow the procedure described in the STANDBY section above (10) before powering up your amp.
1
2
6 7 8
3 4 5 9
10
11
Standby Off
On
Solo
0 dB
-6 dB
Ch1
0 Max 0 Max 0 Max
Bass Middle High
Gain Master Presence
Ch2
0 Max 0 Max 0 Max
Bass Middle High
Gain Master Presence
Ch3
0 Max 0 Max 0 Max
Bass Middle High
Gain Master Presence
Triple 6
Input
Model Little Mark Tube 800 CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE REPLACE ONLY WITH SAME TYPE AND RATING FUSE. ATTENTION: REMPLACER UNIQUEMENT PAR UN FUSIBLE DE MEME TYPE.
Ser.Nr.
Date
120V ~ AC 60Hz Fuse T 8 A 250V - Power 800W
Controller Speaker out Service Bias Ch1 Ch2 Ch3 Loop Solo Speaker out
Total 4 Ω Or 8 Ω + 8 Ω
Load
Total 8 Ω Or 16 Ω + 16 Ω
Load
Total 16 Ω
Load Low
High
Ch
Select Send Return Speaker out LoopAssign
Fsw
Ch1
Ch2
Ch3 All
Off
Send level
Mix
0 Max
Parallel Series Enable
Do not operate this
amplifier without connecting loudspeakers
