Dv Mark OVER MARKER User Manual
Page 7
05
6. TECHNICAL SPECS
InPut
IMPedAnce:
1.5
Mohm / 6 vpp
outPut
IMPedAnce:
100
ohm / 6 vpp
drIve:
+66 dB (maximum gain)
tone:
from 200 Hz to 2.5 kHz
tone 2:
from 0 to -20 dB at 800 Hz
LeveL outPut:
0 to Max
Power requIreMents - dc InPut:
+9/+12vdc or standard 9-volt battery
dIMensIons: 81.8
x 54.8 x 124.5 mm
3.23”
x
2.17”
x
4.92”
weIGHt:
340
g
0.75
lbs
Mark your own preferred settings on the User Setting Chart below.
8.USER SETTINg CHART (MAKE UP YOUR OWN!)
In
distortion
Drive
Tone
1
Tone
2 Level
Out
7. BLOCK DIAgRAM
