Diamond D610 User Manual
Page 3
Dimension (in./mm)
D610
D612
D615
Total Diameter (A)
10.3 in. (261.6 mm) 12.4 in. (315 mm)
15.4 in. (391.2 mm)
Mounting Diameter (B)
9.2 in. (233.7 mm)
11.1 in. (281.9 mm) 13.9 in. (353.1 mm)
Screw Hole Diameter (C)
9.6 in. (243.8 mm)
11.7 in. (297.2 mm) 14.6 in. (370.8 mm)
Mounting Depth (D)
5.6 in. (142.2 mm)
6.2 in. (157.5 mm)
7.4 in. (188.0 mm)
Magnet Diameter (E)
6.5 in. (165.1 mm)
6.5 in. (165.1 mm)
6.5 in. (165.1 mm)
Displacement
0.08 ft
3
(2.26 liter)
0.01 ft
3
(2.83 liter)
0.13 ft
3
(3.68 liter)
Sealed
D610
D612
D615
Vb (ft
3
)
0.625
0.875
2.25
F3 (Hz)/QTC
51/0.625
47/0.715
37/0.787
Pe (W)
800
800
800
Vented
Vb (ft
3
)
1.25
1.25
3.0
Fb/F3 (Hz)
38/31
40/34
30/27
Port (in.) [dia. x length]
(2) 2.5x16
4x20.5
4x11
Pe (W)
600
800
800
THIELE/SMALL PARAMETERS
PHYSICAL DIMENSIONS
ENCLOSURE
Parameter (unit)
D610D2
D610D4
D612D2
D612D4
D615D2
D615D4
SPL (dB)
84
84
85.5
85.5
87
87
Re (Ω) [series]
3.9
6.0
3.9
6.0
3.7
6.0
Qms
5.75
3.97
5.24
4.60
6.00
4.52
Qes
0.55
0.56
0.56
0.57
0.57
0.58
Qts
0.51
0.49
0.51
0.51
0.52
0.51
Fs (Hz)
35.3
40
32.4
34
25.2
28
Vas (L)
8.9
12.3
12.6
33.1
88.5
74
Cms (mm/N)
0.064
0.088
0.070
0.098
0.097
0.081
Mms (g)
325
181
346
223
411
398
Sd (m
2
)
0.032
0.032
0.049
0.049
0.080
0.080
BL (T*M)
22.3
24.9
22.1
24.2
20.6
27.2
Xmax (mm)
17.8
18.3
17.8
16.5
16
15
Pwr (W) NOM/MAX
500/1000
500/1000
600/1200
600/1200
750/1500
750/1500
The enclosures specified below are offered as a suggestion only. Assistance from an authorized
Diamond Audio retailer is recommended for designing the correct system for your vehicle. All volumes
below are shown as gross internal volumes, driver and vent displacement has been accounted for. The
use of a 30Hz sub-sonic filter is recommended on most vented enclosures.
