5.)
Raise the lift to the mounting plate – insert the lugs into the key holes and
slide to narrow side of key hole slot.
6.)
Install the locking screw on the side of the unit.
7.)
There is a 2” long ¾ “ diameter conduit shipped with the unit, use a longer
piece if needed. Lower the microphone and weight down through the hole,
and thread through the conduit, conduit fitting, and ceiling bezel. Run this
assembly up through the hole and lock in place by tightening the upper nut
which if fixed to the bottom of the microphone lift.
8.)
Replace ceiling bezel.
9.)
If you’re installing this unit for purposes other than what the above
installation procedure describes, please call Display Devices Technical
Services at (303) 412-0399 for further assistance.
