Weight frame assembly – Deltech Fitness DF1700- Olympic Bench Press User Manual
Page 4
INSERT WEIGHT HOLDERS (D) INTO WEIGHT FRAME (B). ADJUST HEIGHT OF
WEIGHT HOLDERS (D) WITH PULL-PINS. INSTALL KNOBS (E) AND TIGHTEN TO
LOCK WEIGHT HOLDERS IN PLACE.
INSTALL 2” x 3” CAPS (F) INTO WEIGHT FRAME. IF NECESSARY, TAP IN WITH RUB-
BER MALLET.
*NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533
TOOLS REQUIRED:
METRIC WRENCHES OR SOCKET SET
D
D
E
E
B
F
F
WEIGHT FRAME ASSEMBLY
