1228 Chestnut Avenue • Minneapolis, MN 55403
Delavan Ag Pumps
Document HD Magnum Install 3.15.06
HD Magnum Series
2
HD Magnum Series
Model Number Designations
Pump Size
Port Size - FNPT (inches)
Inlet:
Outlet:
M125
1-1/4
1
M150
1-1/2
1-1/4
M200
2
1-1/2
Material
C
Cast iron with nylon impeller and Viton/ceramic seal (standard)
S
Stainless steel with nylon impeller and Viton/silicon carbide seal (standard)
Hydraulic Motor*
PM21 5-7 GPM, rear ports (for M125 only)
PM37 7-10 GPM, rear ports (for M125 & M150 only)
PM45 11-13 GPM, rear ports
PM58 13-15 GPM, rear ports
PM58B 13-15 GPM, side ports
PM70B 15-17 GPM, side ports
Optional Adders
-VS
Viton/silicon carbide seal (optional for cast iron models)
-PI
Polypropylene impeller
-NS
Nylon impeller with stainless steel insert
-PS
Polypropylene impeller with stainless steel insert
* All hydraulic motors are designed for open and closed center systems. Consult factory for other motor options.
Performance
Hydraulic Hydraulic
Pump Motor
Oil Flow
Pump Flow GPM @ Rated PSIG
Size
Size
(GPM)
10
20
30
40
50
60
70
80
90 100 110 120 130 140
M125 PM21*
5
58
55
51
38
31
17
6
65
64
63
59
54
49
42
34
26
15
7
73
72
70
69
68
64
59
53
45
38
30
22
PM37
7
69
68
66
63
55
44
25
16
8
78
76
75
71
69
61
52
34
15
9
79
77
76
73
70
63
59
46
30
8
M150 PM37*
7
155 144 127 105 65
21
8
175 170 161 145 126 104 78
43
9
180 172 163 151 138 115 88
64
39
PM45
11
180 173 165 152 136 123 101 82
61
32
8
12
185 177 169 160 151 138 121 103 82
63
45
11
13
191 182 174 168 159 145 133 117 101 86
60
36
PM58
13
172 165 159 148 136 124 106 86
66
37
12
PM58B
14
180 172 164 156 147 135 120 104 86
69
51
15
15
185 174 165 159 150 141 131 118 101 88
63
38
PM70B
15
163 157 152 149 145 128 100 64
10
16
171 164 156 153 149 144 135 117 79
51
17
176 167 159 155 150 146 139 121 82
53
M200 PM45*
11
229 221 217 193 180 149 128 111 75
42
29
12
240 136 230 220 205 194 151 137 123 93
81
41
14
13
245 238 229 216 199 186 167 146 122 108 76
55
17
PM58
13
232 226 214 200 184 161 139 110 79
36
PM58B
14
235 229 222 204 190 169 145 124 100 70
44
12
10
15
240 232 226 209 195 179 156 135 110 84
53
32
20
10
PM70B
15
163 157 152 149 145 128 100 64
10
16
171 164 156 153 149 144 135 117 79
51
17
176 167 159 155 150 146 139 121 82
53
*Note: Smaller displacement motors on larger pumps can cause pressures on hydraulic motor to exceed recommended manufacturer’s specifications.
Consult factory for details.
