DeVilbiss FTV560V - Manual

OWNERS MANUAL FOR
Permanently Lubricated Twin Cylinder Air Compressor
SAFETY GUIDELINES - DEFINITIONS
This manual contains information
that is important for you to know and
understand. This information relates
to protecting YOUR SAFETY and
PREVENTING
EQUIPMENT
PROBLEMS. To help you recognize
this information, we use the sym-
bols to the right. Please read the
manual and pay attention to these
sections.
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death of serious injury.
CAUTION indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
CAUTION used without the safety alert symbol indicates a poten-
tially hazardous situation which, if not avoided, may result in
property damage.
10/2/97
Specification Chart
Retain Original Sales Receipt as Proof of
Purchase for Warranty Repair Work.
FTV560V
5
2 3/8"
1.2"
220V/50/1
15 amps
"Fusetron" Type T
60 Gal. ASME
100
125
14.0
10.5
Model No.
Horsepower
Bore
Stroke
Voltage/Hertz/Phase
Minimum Branch Circuit Requirement
Fuse Type
Air Tank Capacity - GAL
Approximate Cut-in Pressure
Approximate Cut-out Pressure
SCFM @ 40 psig
SCFM @ 90 psig
MGP-FTV560VA 9/14/99
