Instructions – Da-Lite Fast-Fold Drapery Surround User Manual
Page 2
2
Instructions
1. Remove parts and drapery from case. Unfold the legs and
lock the braces. Notes: The top section of the leg can remain
folded if the total height is not that high (Figure 1 shows this
folded; Figure 2 shows it unfolded). Also, if this is being used
in the 90º mode only 3 legs are necessary, although all 4
can be used. (Figure 3 shows the braces locked on both skirt
bars. If only 3 legs are used, the attachment bar can remain
unfolded and out of the way.)
2. Unfold the skirt bar and lock the braces. Attach to the legs
with speedy cranks at the necessary height. The height is
adjustable from 37” to 73” in 6” increments. The red color
code will be 37”; the green color code will be 73”.
3. If using in the 90º mode, attach the angle attachment
bracket to the skirt bars using speedy cranks.
4. Snap the drapery to the bar (if using less than the full height,
the drapery should be tucked under carefully to retain a neat
appearance at the legs). (Figure 4)
1
1) Remove parts and drapery from case. Unfold the legs and lock the braces. Notes: The top section of
the leg can remain folded if the total height is not that high (Figure 1 shows this folded; Figure 2 shows
it unfolded). Also, if this is being used in the 90º mode only 3 legs are necessary, although all 4 can
be used. (Figure 3 shows the braces locked on both skirt bars. If only 3 legs are used, the attachment
bar can remain unfolded and out of the way.)
2) Unfold the skirt bar and lock the braces. Attach to the legs with speedy cranks at the necessary
height. The height is adjustable from 37” to 73” in 6” increments. The red color code will be 37”; the
green color code will be 73”.
3) If using in the 90º mode, attach the angle attachment bracket to the skirt bars using speedy cranks.
4) Snap the drapery to the bar (if using less than the full height, the drapery should be tucked under
carefully to retain a neat appearance at the legs). (Figure 4)
1
1) Remove parts and drapery from case. Unfold the legs and lock the braces. Notes: The top section of
the leg can remain folded if the total height is not that high (Figure 1 shows this folded; Figure 2 shows
it unfolded). Also, if this is being used in the 90º mode only 3 legs are necessary, although all 4 can
be used. (Figure 3 shows the braces locked on both skirt bars. If only 3 legs are used, the attachment
bar can remain unfolded and out of the way.)
2) Unfold the skirt bar and lock the braces. Attach to the legs with speedy cranks at the necessary
height. The height is adjustable from 37” to 73” in 6” increments. The red color code will be 37”; the
green color code will be 73”.
3) If using in the 90º mode, attach the angle attachment bracket to the skirt bars using speedy cranks.
4) Snap the drapery to the bar (if using less than the full height, the drapery should be tucked under
carefully to retain a neat appearance at the legs). (Figure 4)
2
2
Figure 1
Figure 3
Figure 2
Figure 4
