Da-Lite Fast-Fold® Deluxe frames are made of 1-1/4” square hard aluminum tubing with an anodized finish. With proper care they will
provide many years of use. Please follow the set up instructions below (steps 1-6).
1. Remove the frame from its case and wrapping. Position it as shown (front view).
2. Unfold the frame following the directions given below so that it is lying flat, snap latches will automatically lock.
Procedure
Two Section Frame
Three Section Frame
Looking From The Top
Rotate 90
o
Top
