5
Senior Electrol ® Instructions
Senior Electrol ® Installation
4 3⁄8"
For Screens Up To 18' X 18'
Motor Compartment
Reinforced
Top
11 5⁄16"
18 5⁄8"
Hinged Access Panel
For Motor Compartment
Fabric Height x Width As Ordered,
Up To 18 Feet x 18 Feet
Length = F
abric W
idth + 23", All Siz
es
4 3⁄8"
10 3⁄4"
Reinforced
Top
18 5⁄8"
Hinged Access Panel
For Motor Compartment
Fabric Height x Width As Ordered,
Up To 20 Feet x 20 Feet Or
Up To 12 Feet High x 24 Feet Wide
Motor Compartment
12 9⁄16"
For Screens 20' And Larger In Height Or Width
Length = F
abric Width + 23", All Siz
es
9 1⁄2"
Up Limit Switch
Down Limit Switch
Black
Black
Black
Black
Black
(Down)
Red (Up)
Black (Do
wn)
Capacitor
R
ed (Up)
White
Whit
e
(Common)
Up
Up
Adj. Down
Adj.
White
White
Black With Yellow
Down
Off
Internal
Wiring
External Wiring
To Be Completed
By Installer
Red
Green
(Ground)
Motor: 120V. 60 Cycles
1/10HP Intermittent Duty
With Auto-Reset Thermal
Protector
Junction Box, Mounted In
Screen Case, In Which Internal
Wiring Terminates In White,
Black and Red Leads.
In Multiple Control Installations
This Switch Is Replaced By The
Low Voltage Control, Operated
From Push Button Stations.
Operating Switch, Switch Box,
And Plate Furnished With Screen.
(SPST With Center Off)
AC Common
AC HOT
120 Vac 60 Hz 1 Amp. Max.
Side View Of
Switch & Box
120V Wiring Diagram
240 Volt Wiring Diagram
For Standard Wall Switch:
Da-Lite offers two styles of 240 volt wall
switches for standard operation. Please see
wiring diagram included in wall switch box
included with screen.
Black Red
