PARTS LIST
(V)T32N, (V)T32NB, (V)T32NR, (V)T32NRB
(V)T32P, (V)T32PB, (V)T32PR, (V)T32PRB, CHDV32NR
PARTS LIST
(V)T32N, (V)T32NB, (V)T32NR, (V)T32NRB, (V)T32P,
(V)T32PB, (V)T32PR, (V)T32PRB, CHDV32NR
This list contains replaceable parts used in your fireplace. When ordering
parts, follow the instructions listed under Replacement Parts on page 34 of
this manual.
KEY
PART
NO.
NUMBER
DESCRIPTION
QTY.
9-15 108886-01
Base Grate Assembly
1
9-16 108891-01
Burner
1
9-17 108084-02
Pilot Assembly (Natural)
1
108084-03
Pilot Assembly (Propane/LP)
1
9-18 108889-01
Burner Base Assembly
1
9-19 27113
Air Deflector
1
10
108890-01
Burner Base Gasket
1
11
108897-01
Rear Refractory Brick Panel
(B Models Only)
1
12
109082-03
Heat Shield
1
13
108901-01
Right Refractory Brick Panel
(B Models Only)
1
14
108901-02
Left Refractory Brick Panel
(B Models Only)
1
15
11418
Push-On Nut
2
16
108440-01
Screen
2
17
109479-01
Screen Rod
1
18
14123
Strain Relief
1
19
21171
Gas Knock-Out Cover
2
20
24353
Handy Box Assembly
1
21
24460
Gas Conduit Assembly
1
22
109222-01
Log Set
1
22-1 109403-01
Front Log (Log 1)
1
22-2 109404-01
Rear Log (Log 2)
1
22-3 109407-01
Base Log (Log 3)
1
22-4 109406-01
Crossover Log (Log 4)
1
22-5 109405-01
Left Top Log (Log 5)
1
22-6 109408-01
Right Top Log (Log 6)
1
PARTS AVAILABLE - NOT SHOWN
25487
Lava Rock/Bag Assy
1
PCDM-32T
Conversion Kit (CHDV32NR only)
1
KEY
PART
NO.
NUMBER
DESCRIPTION
QTY.
1
**
Firebox Assembly
1
2
**
Face Weldment
1
3
108892-01
Door Assembly (T & CHDV Models Only)
1
108892-02
Door Assembly (VT Models Only)
1
4
109155-01
Top Stamped Panel Assy
1
T32N/P, T32NB/PB Models
108903-01
Top Rolled Louver Assy T32NR/PR,
1
T32NRB/PRB & CHDV32NR Models
5
109155-02
Bottom Stamped Panel Assy
1
T32N/P, T32NB/PB Models
108903-02
Bottom Rolled Louver Assy (T32NR/PR,
T32NRB/PRB, CHDV32NR Models)
1
6
108895-01
Fireplace Top
1
7
**
Fireplace Top Insulation
1
8
**
Fireplace Surround
1
9
108885-01
Burner Assembly (Natural)
1
108885-02
Burner Assembly (Propane/LP)
1
9-1
11102
Screw #8-32 x 3/8 PPH Zinc
2
9-2
11105
Screw #10 x 1/2 Zinc
9
9-3
11179
Screw #10-24 x 1/4 Zinc
4
9-4
11237
Screw, Trilab M4 x 8mm
1
9-5
14389
Millivolt Valve (Natural)
1
14390
Millivolt Valve (Propane/LP)
1
9-6
14492
Piezo Ignitor
1
9-7
14500
Brass Fitting
2
9-8
14253
Flexible Connector
1
9-9
14511
Ignitor Bracket
1
9-10 14528
Brass Elbow Fitting
1
9-11 104506-25
Orifice (Natural)
1
14514
Orifice (Propane/LP)
1
9-12 104509-02
Aluminum Tubing Assy
1
9-13 26808
Valve Bracket
1
9-14 26827
Switch Bracket
1
** Not a field replaceable part.
