Page 33
ALPHA BEAM 700
BIT
EFFECT
255
COLOUR EXCLUDED
0
COLOUR INSERTED
CHANNEL 1
CYAN
CHANNEL 2
MAGENTA
CHANNEL 3
YELLOW
BIT
EFFECT
255
COLOUR INSERTED
0
COLOUR EXCLUDED
CHANNEL 1
CYAN
CHANNEL 2
MAGENTA
CHANNEL 3
YELLOW
• COLOUR MIXING - channel 1 - 2 - 3
Operation with option color mixing: RGB
Operation with option color mixing: CMY
• COLOUR WHEEL - channel 4
BIT
EFFECT
255
FAST ROTATION (160 rpm)
128
127
120
112
105
97
90
82
75
67
60
52
45
37
30
22
15
8
0
SLOW ROTATION (0.2 rpm)
BLUE + WHITE
BLUE
ORANGE + BLUE
ORANGE
AQUAMARINE + ORANGE
AQUAMARINE
GREEN + AQUAMARINE
GREEN
CTO 2500 + GREEN
CTO 2500
CTO 3200 + CTO 2500
CTO 3200
CTB+ CTO 3200
CTB
RED + CTB
RED
WHITE + RED
WHITE
IMPORTANT: The lamp dim to half power 1 second after all the 3 channels stay at 255 bit level.
The lamp goes back to full power when the channels level is put lower than 255 bit.
IMPORTANT: The lamp dim to half power 1 second after all the 3 channels stay at 0 bit level.
The lamp goes back to full power when the channels level is put higher than 0 bit.
• STOP / STROBE - channel 5
IMPORTANT: The lamp dim to half power 1 second after the channel stay at 0 bit level.
The lamp goes back to full power when the channel level is put higher than 0 bit .
MA
CR
O
BIT
EFFECT
252 - 255
OPEN
0 - 3
CLOSED
213 - 225
RANDOM SLOW STROBE
4
SLOW STROBE (1 flash/sec)
103
FAST STROBE (12 flash/sec)
104 - 107
OPEN
108
SLOW PULSATION
208 - 212
OPEN
226 - 238
RANDOM MEDIUM STROBE
239 - 251
RANDOM FAST STROBE
207
FAST PULSATION
The lamp is linearly dimmed from full power to half power electronicaly and
mechanically from half power to off.
• DIMMER - channel 6
BIT
EFFECT
255
0
• DIMMER FINE - channel 7
BIT
EFFECT
255
0
0
MINIMUM APERTURE
252 - 255
MAXIMUM APERTURE
BIT
EFFECT
251
FAST PULSATION, FAST CLOSING
212
SLOW PULSATION, FAST CLOSING
211
FAST PULSATION, FAST OPENING
172
SLOW PULSATION, FAST OPENING
171
FAST PULSATION
132
SLOW PULSATION
128 - 131
MAXIMUM APERTURE
MA
CR
O
• IRIS - channel 8
NOTE: On conclusion of resetting in case of absence of DMX signal, Pan & Tilt move to the "Home" position (Pan 128 bit - Tilt 128 bit) all the others channels stay at 0 bit.
33
