Dodge 2005 PL Neon SRT4 User Manual
Page 172

5
10 Amp/Red
Airbag Run Only
6
20 Amp/
Yellow
HVAC Blower
7
10 Amp/Red
Backup Switch/EBL/
Temp/Comp
8
15 Amp/Lt.
Blue
High Headlamp
9
10 Amp/Red
Airbag Run-Start
10
15 Amp/Lt.
Blue
ABS Engine Run Start
11
10 Amp/Red
ARKEM Run Start
12
10 Amp/Red
Ignition Off/Run/ Start
13
20 Amp/
Yellow
Power Seat Height Adjust
14
20 Amp/
Yellow
ARKEM Door Locks
15
15 Amp/Lt
Blue
Exterior Lighting
16
25 Amp/
Natural
Headlamp
17
10 Amp/Red
Lt Low Beam Headlamp/
Headlamp Level Switch
(Bux Only)
18
10 Amp/Red
Rt Low Beam Headlamp/
Headlamp Level Motor
19
10 Amp/Red
Fog lamps
20
Spare
CAUTION!
When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a
properly rated fuse continues to blow, it shows a
problem in the circuit that must be corrected.
172
MAINTAINING YOUR VEHICLE
