2.2 Installing Hard Disk & Memory
Step 1.
Memory Installation:
Remove 3 screws to release the chassis cover, and remove it.
Step 2.1 Insert the SODIMM into the memory socket.
Step 2.2 Re-assemble your system back through previous steps to complete the installation.
