Avalue LPC-1507 - Manual (Page 6)

LPC-1507
6 LPC-1507 Quick Reference Guide
Display Memory CRT mode: 1920 x 1200 @ 60Hz
Resolution LCD/Simultaneous mode :1400 x 900 @ 60 Hz (CDV-D)
Dual Display HDMI + LVDS
Audio
AC97 Codec Realtek ALC892 supports 5.1-CH Audio
Audio Interface Speaker out, Line-out
Ethernet
LAN Chip Intel® 82574L Gigabit LAN, Optional Dual LAN
Ethernet Interface 10/100/1000 Base-Tx Fast Ethernet compatible
Mechanical &
Environmental
System Fan Fanless
Color Front Silver & Rear panel Black
Mounting Wall/Stand/VESA 75 mm x 75 mm
Power Input 100~250 Vdc/ 47~63 Hz
Power Output +12 Vdc / 5 A (60W)
ACPI n/a
Power Type AT/ATX
Operating Temp. 0 to 40°C
Storage Temp. -10 to 60°C
Operating
Humidity
5%~90% relative humidity, non-condensing
Dimensions 351.5 x 272 x 52 mm
Weight 4.2 Kgs
