LPC-1508
6 LPC-1508 Quick Reference Guide
Dual Display Intel® Lynx Point Integrated w/ CPU
Audio
AC97 Codec Realtek ALC892 supports 5.1-CH Audio
Audio Interface Speaker (2x1W), Line-out
Ethernet
LAN Chip 1 x Intel® I210 GbE controller, 1 x Intel® I218LM GbE PHY
Ethernet Interface 10/100/1000 Base-Tx Fast Ethernet compatible
Mechanical &
Environmental
System Fan Fanless
Color Front Silver & Rear panel Black
Mounting Wall/Stand/VESA 75 mm x 75 mm/ 100mm x 100mm
Power
Requirement
+12 V ~ +26 V
Power Adapter
Input: 100 ~ 240 Vac/ 50 ~ 60 Hz
Output: +12 Vdc / 5 A (60W)
ACPI n/a
Power Type AT/ATX (ATX mode is default)
Operating Temp. 0 to 40°C
Storage Temp. -10 to 60°C
Operating
Humidity
5%~90% relative humidity, non-condensing
Dimensions 350 x 273.9 x 53.1 mm
Weight 4.2 Kgs
