SPC 12 ”/15”/17”/22”W Series
10 SPC 12 ”/15”/17”/22”W Series Quick Reference Guide
Panel
Model
SPC-22W3 SPC-22W5
LCD size 22 ”W, 16:10
Display type WSXGA
Resolution 1680 x 1050
Color 16.7M
Pixel pitch 0.282mm(H) x 0.282mm(V)
Luminance 300 cd/m²
Contrast ratio 1000
Viewing angle 80(U), 80(D), 85(L), 85(R)
Response time 5 ms
Backlight CCFL
Touch type 5 Wires resistive
Touch interface USB
System
Board EBM-945GSE EBM-PNV
CPU
Onboard Intel Atom N270 1.6GHz
(2.5W)
Onboard Intel® Atom™ D525 Dual-Core
1.8GHz CPU
BIOS Award 4 Mbit Flash BIOS AMI 8 Mbit Flash BIOS
System Chipset Intel 945GSE + ICH7-M Intel® ICH8-M Chipset
I/O Chipset ITE 8712F Winbond W83627DHG-P
System Memory
Onboard 1GB DDR2, extra one
SODIMM supports up to 2GB 400/533
SDRAM
Onboard 1GB, One 200-pin SODIMM
Support Up to 3GB SDRAM
SSD
One CF socket supports Type I / II
Compact Flash Card.
One CF socket supports Type I / II
Compact Flash Card.
HDD
Optional 2.5 ” SATA HDD or 44-pin
enhanced IDE HDD
One 2.5” SATA HDD
WiFi Optional USB WiFi 802.11b/g Optional USB WiFi 802.11b/g/n
Watchdog Timer
Reset: 1 ~ 65535 sec./min. and 1
min./step
Reset: 1 ~ 255min. and 1sec. or
1min./step
Display
Intel 945GSE GMCH integrated
GMA950 graphics
Intel Pineview integrated, Gen3.5 + GFX
Core @ 400MHz (PNV-D)
Audio Realtek ALC 655 supports 5.1-CH Audio Realtek ALC 888 supports 5.1-CH Audio
Ethernet
Dual Realtek RTL8111C Gigabit LAN Intel® 82574L Gigabit Ethernet
