Quick Reference Guide
SPC-1507 Quick Reference Guide 5
1.3 System Specifications
Panel
Board EBM-CDV
CPU Onboard Intel® Cedarview D2550 1.86GHz CPU
System Chipset Intel NM10 Express
I/O Chip E/C IT8518E
System Memory One SODIMM socket supports up to 4GB DDR3 800/1066 SDRAM
SSD One CompactFlash Type I/ II Socket (Support optional InnoDisk CF-SATA)
Hard Driver Bay One 2.5" SATA HDD
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
Monitoring system temperature, voltage, and cooling fan status. Auto
throttling control when CPU overheats
Expansion 1 x Mini PCIe slot, optional supports mSATA
Rear I/O
Serial Port 1 x RS-232
Ethernet 1 x RJ-45
USB 3 x USB 2.0
Speaker 2 x 2W
Display
Chipset Intel® Cedarview Integrated Graphics
Resolution
CRT Mode: 1920 x 1200 @ 60Hz; LCD/Simultaneous Mode : 1400 x 900 @
60Hz (CDV-D)
Dual Display LVDS + HDMI
Audio
AC97 Codec Realtek ALC892 supports 5.1-CH Audio
Audio Interface Speaker out, Line-out
Ethernet
LAN Chip Intel® 82574L Gigabit LAN
Ethernet Interface 10/100/1000 Base-Tx Fast Ethernet compatible
Mechanical &
Environmental
System Fan Fanless
Color Front & Rear Panel Silver
Mounting Wall/Stand/VESA 75 mm x 75 mm
Power Requirement +12 V ~ +26 V
Power Adapter
Input: 100~240 Vac/ 50~60 Hz
Output: +24 Vdc / 2.5 A (60W)
