1.4 System Overview

1.4.1

SPC-1209 Rear View

Connectors

Label

Function

Note

DC-IN

Waterproof DC Power-in connector

18pin

Waterproof 18pin connector

(Use attached cable to convert 1xUSB/1xLAN/1xCOM)

USB

Waterproof USB 2.0 connector x 2

1.4.2

SPC-1709 Rear View

Connectors

Label

Function

Note

Membrane

Power & 3 programmable buttons

USB

Waterproof USB 2.0 connector x 3

COM

Waterproof DB-9 connector

LAN

Waterproof RJ-45 connector

DC-IN

Waterproof DC Power-in connector
