Quick Reference Guide
AID-173SHW Quick Reference Guide 5
1.3 System Specifications
Component
Mother Board Proprietary and Custom Made
CPU
(1) Intel® Core™ i7-4650U Processor (4M Cache, up to 3.30 GHz)
FC-BGA12F, Tray
(2) Intel® Core™ i5-4300U Processor (3M Cache, up to 2.90 GHz)
(3) Intel® Core™ i3-4010U Processor (3M Cache, 1.70 GHz)
CPU Cooler (Type) Passive
Memory
DDR3L 1600
1 x SODIMM sockets
Maximum 8GB Capacity
Power Supply 12 ~ 19V Wide Range Input
Adapter 60W [email protected] IEC/EN 60601-1 Medical Adapter
System Fan Fan-less
Microphone 1 x System Microphone
Speaker 2 x 2W High Quality System Speakers
Camera 1 x 2.0M Camera
Wireless LAN Optional 1 x 802.11 b/g/n wireless LAN
Bluetooth Optional External USB Bluetooth Dongle
Operating System Win7/Win8/Linux
Other Component SCR/MSR/RFID/Barcode Scanner / VOIP Handset
Storage
Solid State Drive 1 x 2.5” 32G SATA SSD
Panel
LCD Panel 17. 3” TFT-LCD 1920*1080 from AUO / CMO-Innolux
LCD Control Board LCD Built-in Inverter
B/L
Inverter/Converter
LCD Built-in LED Backlight
Touch Screen
17.3 ” Projected Capacitive Touch Panel
17.3 ” Resistive Touch Panel
Touch Controller Projected Capacitive Touch Controller
Built-in Touch controller
External I/O
Serial Port
1 x RS-232
1 x RS-232/422/485
USB Port
1 x USB 3.0 Port
3 x USB 2.0 Port
