EPC-CDV
10 EPC-CDV Quick Reference Guide
2.1 EPC-CDV connector list
Connectors
Label Function Note
COM1 Serial port 1 connector
COM2/DVI Serial port 2 connector
Compact Flash Compact Flash card connector Type I/II x 1
12V DC-IN DC power-in connector
LAN1 RJ-45 Ethernet 1
LAN2 RJ-45 Ethernet 2
LINE IN Line-in audio jack
LINE OUT Line-out audio jack
MIC IN Mic-in audio jack
HDD HDD indicator
USB1~5 USB 1~5 connector
PWR System power indicator
VGA VGA connector D-sub 15-pin, female
HDMI HDMI connector
