EMX-CDT User ’s Manual
EMX-CDT User ’s Manual 33
3.6.2.7.2 Parallel Port Configuration
Item Options Description
Parallel Port
Enabled[Default],
Disabled
Enable or Disable Parallel Port (LPT/LPTE).
Change Settings
Auto[Default]
IO=378h; IRQ=5;
IO=378h; IRQ=5,6,7,10,11,12
IO=278h; IRQ=5,6,7,10,11,12
IO=3BCh; IRQ=5,6,7,10,11,12
Select an optimal setting for Super IO device.
Device Mode
STD Printer Mode[Default]
SPP Mode
EPP-1.9 and SPP Mode
EPP-1.7 and SPP Mode
ECP Mode
ECP and EPP 1.9 Mode
ECP and EPP 1.7 Mode
Change the Printer Port mode.
3.6.2.8 WatchDogTimer Setting
Item Options Description
WatchDogTimer
Enabled,
Disabled[Default]
WatchDogTimer Setting
