AVALON RF, INC. Page 1
TX500 Series User’s Guide & Operating Manual
1. General
The TX500 series rugged transmitters are intended for use in military,
homeland security, mobile security, broadcasting and motion picture
production.
The TX500 Series is an FM modulated transmitter with a tuning range
that is model dependent. See table below for frequency ranges.
Model Frequency Range
TX5XX-00 900-1100 MHz
TX5XX-01 1100-1300 MHz
TX5XX-02 1300-1600 MHz
TX5XX-03 1600-1900 MHz
TX5XX-04 1900-2200 MHz
The following table details the RF output power of the various models:
Model Output Power
TX518 70mW
TX523 200mW
TX530 900mW
Table 1 – Model/Output Power
The Transmitter connector is a high density DB-15.
