Pi-Ko 6 english
Chimney fire
A chimney fire may occur, due to sooting and
deposits in the chimney, if wrong or humid fuel is
used. Close all air inlets on the fireplace/chimney
immediately and call the fire brigade. Please have an
expert inspect your chimney for cracks and air-
tightness after the burning out of the chimney.
4. THE MOST IMPORTANT SPARES—OVERVIEW
Keramott
Description Nr. drawing Part number
Bottom Keramott left 1 714690
Bottom Keramott right 2 714691
Bottom Keramott rear 3 714692
Bottom Keramott front 4 714695
Rear Keramott 5 714693
Side Keramott 6 714694
Protection panel 7 714639
Keramott baffle plate 8 714696
Grate 9 716408
Other parts
Description Nr. drawing Part number
Door 10 714658-29
Glass 11 714659
Door handle 12 714466
BA 1 spring 13 714663-15
Stove lacquer -- 650002
Glass cleaner ½ litre -- 640070
Gaskets
Description Nr. drawing Part number
Flat gasket 8 x 2 mm (1,6 m) 14 710096
Round gasket 14 mm (1,7 m) 15 714223
Accessories
You can obtain floor plates of glass or steel, fireplace utensils and care products.
IMPORTANT: Have defective parts replaced by your certified dealer. This will guarantee that your
stove functions properly and safely.
The fireplae must not be amended.
Maintenance
To clean the glass, please use a specialized product such as Thermohit glass cleaner. Lacquered
surfaces are to be cleaned only with a cloth (may be damp). Special cleaning agents should also be used
for stainless steel surfaces.
Cleaning
The stove, flue outlets and smoke pipes should be cleaned and inspected for deposits every year – if
necessary more often, e.g. after the cleaning of the chimney. The chimney also has to be cleaned
regularly by the chimneysweeper. Your chimneysweeper will inform you of the necessary inspection
intervals. An expert should inspect the stove annually.
order of Keramott installation acc. to numbering!
