english 5 Jess Xtra
1. TECHNICAL DATA
As a stove of construction type 1, it is possible to
connect it to the chimney together with an exisiting
other stove or another hearth for solid fuels, as long
as the chimney caleutation complies with DIN 4705,
Part 3.
TECHNICAL DATA
Height 1186 mm
Width 898 mm
Depth 503 mm
Weight 288 kg
Flue pipe outlet diameter
150 mm
Nominal thermal output (EN 13240) 8 kW
Maximum thermal capacity 11 kW
Smallest heating capacity
4 kW
Room heating capacity (depending on
building insulation) 98 – 255
m³
Exhaust values for multiple use of the chimney in
accordance with DIN 4705, Part 3 and for the
calculation of the chimney measurements in
accordance with DIN 4705, Part 2
Fluegas mass flow
closed 6,49 g/s
Fluegas temperature closed 332 °C
Minimum feed pressure
Nominal thermal output
closed 12 Pa
at 0.8 times
n. ther. outp. 10 Pa
2. IMPORTANT INFORMATION
The installation and operation information given here
is of general nature. National and European
standards, local and building regulations as well as
fire prevention laws must be observed during the
operation of the stove
.
General safety instructions for
the operation of your stove
• Thoroughly read the entire manual before
starting up your stove and observe the caution
notices.
• Your heating unit may not be moved without
approved means of transport with sufficient load-
bearing capacity.
• Your heating unit is not suitable to be used as a
stand or as a ladder.
• Please keep in mind that
your stove’s surface heats up
considerably during operation. We
therefore recommend wearing a
safety mitten when operating your
stove.
• Make your children aware of this particular
danger and keep them at a distance from the heating
unit whenever it is in operation.
• Only burn approved fuels and materials listed in
the chapter “Clean Burning”.
• The burning or placing of flammable or explosive
materials, such as empty spray cans and such like
into the firebox as well as the storage of such
materials in the immediate vicinity of your heating unit
is strictly forbidden due the danger of explosion.
• Do not wear loose or flammable clothing when
adding fuel to the fire.
• Placing non-heat-resistant objects on the
heating unit or in the vicinity of the heating unit is
forbidden.
• Do not lay laundry onto the stove for drying.
Laundry hung up to dry must be kept at a safe
distance from the stove because of the danger of fire.
• The woodstove Jess Xtra is not suitable for long
term heating.
•
During the operation of your heating unit it is
forbidden to use flammable or explosive materials in
the same or an adjacent room to the one in which
your heating unit is located.
Setting up your stove
Required safety distances
(Minimum
distances – see name plate - in Fig. 2)
a > 800 mm
b > 200 mm
*) c > 380 mm
(a – toward the front in the radiated area)
(b – to the side)
(c – to the back)
*) When using the rear protection plate, the safety
distance reduces to 130 mm (accessory ref. 065003)
Make sure that the room in which the stove is set up
has at least one door or window into the outside or is
directly adjacent to such a room. Other fireplaces and
extractor hoods must not be operated in the same
room as the stove
.
Subject to technical and optical m
odificati
ons. Formatting and printi
ng erro
rs excepted.
