< 2.2 > Structure Diagram - OP-W32 32” FHD LCD Display
Front view
Rear view
Rear case
LCD panel
Universal open frame mounting
Audio speaker, pair
LCD membrane
Extended remote sensor membrane cable
( 66cm from AD board to sensor end )
1
2
3
4
5
Top view
6
6
OP-W32
P.7
4
Model
Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
OP-W32
799 x 77 x 493 mm
31.5 x 3 x 19.4 inch
910 x 195 x 580 mm
35.8 x 7.7 x 22.8 inch
16.4 kg
36.1 lbs
21.2 kg
46.6 lbs
1
2
5
3
