LCD panel
Installation Slide
Audio speaker ( for HDMI or Audio option )
1
2
3
4
5
5
LCD OSD membrane
Carry handle to release the 2-pt lock
2-point lock
< 1.1 > Package Content
P.1
< Part 1 >
RP-H117 or RP-H119 unit X 1
- 6ft VGA cable X 1
- Power cord X 1
- M6 screw, cage nut & cup washer X 8
< 1.2 > Structure Diagram
The above package content is only for the pure model ( VGA and DVI-D only ).
It varies with options such as HDMI, AV, audio, touchscreen & DC power.
RP-H117 / H119
6
3
6
