UM-CV-751-SP-117-Q215V1 www.austin-hughes.com

1

2

LCD panel

Installation Slide

LCD OSD membrane

1

2

3

4

5

4

Carry handle to release the 2-pt lock

2-point lock

< 1.1 > Package Content

P.1

< Part 1 >

SP-117 or SP-119 unit X 1
- 6ft VGA cable X 1
- Power cord X 1
- M6 screw, cage nut & cup washer X 8

< 1.2 > Structure Diagram

The above package content is only for the pure model ( VGA and DVI-D only ).

It varies with options such as DC power.

SP-117 / 119

5

3
