UM-CV-751-RP-F117-Q215V1 www.austin-hughes.com
< 3.3 > Options : Touchscreen & driver
Model TRB e-Resistive
Technology 5-Wire Resistive
Touch Point Single
Method Stylus or Finger
Activation Force ≤ 50g / Stylus=R0.8
Durability 10 million touches
Response Time 15 ms
Optical Transmittance 80% ± 3%
Surface Hardness 3H
Haze 8% ± 3%
Glass 2.2 ±0.2 mm
Connector USB Type A
Compatibility Windows 7 / XP / Vista, Linux
P.10
F17" USB Touchscreen Specifi cation
Step 1. Run the bundled CD disc or download the driver from the link below :
http://www.austin-hughes.com/downloads/RMDL/software.html
Step 2. Double click the Setup.exe
Step 3. Follow the installation instruction to fi nish the setup
Step 4. After installation, run the TouchKit program & the “4 point calibration”
Please follow the below steps to setup the touch screen:-
Please do the initial calibration
after the fi rst setup
■
USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc
■
For detailed information, please refer to the attached CD disc
■
As the touchscreen unit is not made of toughened glass, please handle it carefully
For touchscreen option, casing depth will be extended from 480mm ( 18.9" ) to 530mm ( 20.9" )
***
Power
VGA
DVI-D
USB Touchscreen
