Page 16

UM-CV-751-RP-W719-Q215V1 www.austin-hughes.com

USB Touchscreen

Power

VGA

DVI-D

Model

TRB

e-Resistive

TCB

e-Capacitive

Technology

5-Wire Resistive

Capacitive

Touch Point

Single

Method

Stylus or Finger

Finger

Activation Force

≤ 50g / Stylus=R0.8

≤ 50g

Durability

35 million touches

300 million touches

Response Time

15 ms

20 ms

Optical Transmittance

80% ± 3%

87% ±2%

Surface Hardness

Haze

8% ± 3%

Glass

3.2 ±0.2 mm

2.8 mm ±10%

Connector

USB Type A

Compatibility

Windows 7 / XP / Vista, Linux

< 3.6 > Options : Touchscreen & driver

P.12

W19" USB Touchscreen Specifi cation

Step 1.

Run the bundled CD disc or download the driver from the link below :

http://www.austin-hughes.com/downloads/RMDL/software.html

Step 2.

Double click the Setup.exe

Step 3.

Follow the installation instruction to fi nish the setup

Step 4.

After installation, run the TouchKit program & the “4 point calibration”

Please follow the below steps to setup the touch screen:-

Please do the initial calibration
after the fi rst setup

■

USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc

■

For detailed information, please refer to the attached CD disc

■

As the touchscreen unit is not made of toughened glass, please handle it carefully
