Austin Hughes RP-F821 - Manual (Page 5)

UM-CV-751-RP-F821-Q215V1 www.austin-hughes.com
Basic I/O
AV3.0 upgrade
Options
Power VGA DVI-D HDMI
Audio
out - in - in
Video PC
S-Video BNC
: DVI-D + VGA + HDMI w/ speaker
: DVI-D + VGA + HDMI + BNC + S-Video + audio
: SDI, USB for touchscreen & DC power
LCD panel
LCD membrane
Latch to release the display panel from the
rear bracket
Rear mounting bracket
Power adapter basket
< 1.1 > Package Content RP-F821
P.1
< Part 1 >
RP-F821 unit X 1
- 6ft VGA cable X 1
- Power adapter X 1
- Power cord X 1
- Fastener screw for rear bracket x 2
< 1.2 > Structure Diagram
1
3
Front view
3
1
2
Rear view
4
2
4
Power adapter
Power cord
5
5
