Basic I/O
AV3.0 upgrade
Options
Power VGA DVI-D HDMI
Audio
out - in - in
Video PC
S-Video BNC
: DVI-D + VGA
: DVI-D + VGA + HDMI + BNC + S-Video + audio
: SDI, USB for touchscreen & DC power
< 1.1 > Package Content
P.1
< Part 1 >
RP-F617 unit X 1
- 6ft VGA cable X 1
- Power adapter X 1
- Power cord X 1
< 1.2 > Structure Diagram
1
2
Front view
Rear view
4
Power adapter
Power cord
3
LCD panel
LCD membrane
Audio speaker
Power adapter basket
1
2
3
4
