< 1.1 > Package Content
P.1
< Part 1 >
DS117 or DS119 unit X 1
- CX-6 6ft DVI-D console cable X 1
( Alternative : CB-6 6ft VGA console cable )
- Power cord X 1
- M6 screw, cage nut & cup washer X 8
< 1.2 > Structure Diagram
The above package content is only for the single console models.
It varies with options such as KVM & DC power.
DS117 / 119
