Austin Hughes NS119 - Manual (Page 6)

UM-CV-751-NS117-Q215V1 www.austin-hughes.com
8
1
3
7
6
7
9
8
LCD interchangeable module kit
Micro switch for screen auto power off
Keyboard interchangeable module kit
Mouse interchangeable module kit
4
9
5
2
6
Carry handle to release the 2-pt lock
2-point lock
Installation Slides
LCD membrane
Membrane switch (KVM option)
1
2
3
4
5
NS117 or NS119 unit X 1
- CX-6 6ft DVI-D console cable X 1
( Alternative : CB-6 6ft VGA console cable )
- Power cord X 1
- M6 screw, cage nut & cup washer X 8
The above package content is only for the single console models.
It varies with options such as KVM & DC power.
< 1.1 > Package Content
P.1
< Part 1 >
< 1.2 > Structure Diagram
