H117 / 119
Physical
Specifi cation H117 H119
Product ( W x D x H ) 441.6 x 480 x 44 mm 441.6 x 520 x 44 mm
17.4 x 18.9 x 1.73 inch 17.4 x 20.5 x 1.73 inch
Packing ( W x D x H ) 590 x 808 x 140 mm 590 x 808 x 140 mm
23.2 x 31.8 x 5.5 inch 23.2 x 31.8 x 5.5 inch
Net Weight 12.5 kgs / 27.5 lbs 13.2 kgs / 29 lbs
Gross Weight 17.5 kgs / 38.5 lbs 18.2 kgs / 40 lbs
Applicable
Format VGA Input PC Signal 1280 x 1024 x 60 / 75Hz
1280 x 960 x 60Hz
1280 x 760 x 60 / 75Hz
1152 x 864 x 75Hz
1024 x 768 x 60 / 70 / 75Hz
848 x 480 x 60Hz
800 x 600 x 60 / 72 / 75Hz
720 x 400 x 70Hz
640 x 480 x 60 / 72 / 75Hz
640 x 400 x 70Hz
640 x 350 x 70Hz
P.8
Environmental
Conditions Operating Temperature 0 to 55°C degree
Humidity 20~90%, non-condensing
Storage Temperature -5 to 60°C degree
Humidity 5~90%, non-condensing
Shock 10G acceleration (11ms duration)
Vibration 5~500Hz 1G RMS random
