< 1.1 > KVM port connection
P.1
DVI-D KVM
DVI KVM Cable
CI - 6 : 6 feet DVI KVM cable
CI - 15 : 15 feet DVI KVM cable
( Server end : DVI-D + USB + Audio )
( KVM port : DVI-D + USB3.0 )
1
7 12
3 2 6 5 4
9 8 11 10
DVI-D KVM port
USB Servers
USB Servers
Power Audio
IP console, remote console, daisy-chain and OSD menu are NOT available for this model.
