Page 7
UM-CV-751-MKVM-KIT-Q215V3 www.austin-hughes.com
Internet
Remote
USB console
Remote
Cat6
Console 1
CAT 5 / 6 cable
max. 100m
Network device
hub or router
Network device
hub or router
Receiver
CAT 5 / 6 cable
max. 100m
CAT 5 / 6 cable
max. 150m
2
1
Internet
Drawer KVM Rear Kit
P.3
< 1.3 > IP & Remote console connection
Matrix DB-15 IP KVM
