Physical
Product dimensions ( 1U ) 442 x 270 x 43.5 mm ( W x D x H )
Packing dimensions ( 1U ) 530 x 380 x 80 mm ( W x D x H )
Net weight 4.6 kg / 10.1 lb
Gross weight 5.1 kg / 11.2 lb
Product dimensions ( 2U ) 442 x 270 x 87.5 mm ( W x D x H )
Packing dimensions ( 2U ) 530 x 380 x 140 mm ( W x D x H )
Net weight 6.5 kg / 14.3 lb
Gross weight 7 kg / 15.4 lb
Chassis color / materials Dark / Steel
Electrical
Nominal input voltage 110V
Acceptable input voltage ±10% nominal
Input frequency 50 / 60Hz
Inlet plug & cord 2 x NEMA 5-15P / L5-20P plug with 3-meter cord
Outlet connectors Multiple NEMA 5-20R outlets
Local meter 3-digital LED current meter
Overload protection
1 x 15-amp circuit breaker for NEMA 5-15P inlet
1 x 20-amp circuit breaker for NEMA L5-20P inlet
Transfer time 25ms maximum
Electrical endurance 1 x 10 5 operations
Power consumption Approx. 8VA
Environmental
Operating temperature -5 to 45°C degree ( 23 to 113°F )
Storage temperature -25 to 65°C degree ( 13 to 149°F )
Operating humidity 0~95%, non-condensing
Storage humidity 0~95%, non-condensing
Compliance
EMC FCC & CE certifi ed
Safety LVD certified
Environment RoHS2 & REACH compliant
< 2.3 > 110V ATS Specifi cation
