33
NO PART CODE PART NAME DESCRIPTION Q'TY
A00
3511710300 DOOR AS KOR-63150S 1
3511714400
DOOR AS KOR-631H9A 1
3516721410 CONTROL-PANEL AS KOR-631G0A 1
B00 3516721420 CONTROL-PANEL AS KOR-631H0A 1
3516721230 CONTROL-PANEL AS KOR-631H9A 1
F01 3510801310 CABINET PCM T0.36 GE 1
F02 3516004100 SPECIAL SCREW T1 TRS LR4 POLE 4*10 MFZN 3
F03
3516109000 CAVITY WELD AS CAVITY WELD AS 1
3516109600 CAVITY JOINT AS CAVITY WELD AS 1
F04 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 1
F05 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1
F06 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1
F07 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 1
F08 35113NAN0H CORD POWER AS 3X18AWG 60X60 120-RTML 1
F09 4413A90012 CLAMP POWER CORD NYLON66 1
F10 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1
F11 7121403011 SCREW TAPPING T2S PAN 4X30 MFZN 2
F12
3963821600 MOTOR SHADED POLE 120V 21W OEM-10DWX1-A07 1
3963821620 MOTOR SHADED POLE 120V 21W MW08XA-A01 KOR-631G/H9A
F13 3512517000 GUIDE WIND PP 1
F14 3511800300 FAN PP+30%GLASS 1
F15 3518002200 MAGNETRON 2M218H(MF) I 1
F16 3516004000 SPECIAL SCREW T2 BOLT FLANGE 5X12 DACRO 1
F17 7272400811 SCREW SPECIAL TT3 TRS 4X8 SE MFZN 1
F18 3513003200 HOLDER HV CAPACITOR SECC T0.6 1
F19
3518301600 CAPACITOR HV 2100VAC 0.79µF #187 1
3518301501 CAPACITOR HV 2100VAC 0.77µF #187 KOR-631G/H9A
F20 3518400400 DIODE HV HVR-1X-3AB 12KV #187 1
F21
3518114400 TRANS HV JMOT-N80A0-63T KOR-631G/H9A
3518114450 TRANS HV DT-N70A0-63T 1
F22 3516003700 SPECIAL SCREW TT3 HEX 4X8 FLG MFZN 4
F23 3510311700 BASE SBHG T0.8 1
F24 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 5
F25 3512100900 FOOT PP DASF-130 2
F26 7S422X4081 SCREW TAPTITE TT3 TRS 4X8 MFZN 1
F27 3515201101 STOPPER HINGE *U SCP-1 1
F28 - FUSE 120/250V 15A 1
F29 4415A17352 HOLDER FUSE NYLON66 1
F30 4415A17352 SW MICRO VP-533A-OF SPNO #187 200G 1
F31 4415A66600 SW MICRO VP-532A-OF/SZM-V16-FA-62 1
F32
4415A17352 SW MICRO VP-533A-OF SPNO #187 200G 1
3518571000 SW MICRO MP101C KOR-631G/H9A
F33 3513702600 LEVER LOCK POM 1
1) KOR-631G0A/631H0A/631H9A/631G9A
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
