EN ENGLISH
-4- American Sanders Operator's Manual (EN) - OBS-18/18DC HDTR
Model OBS-18DC
Code Number 07014A
Voltage/Frequency 115V/60Hz
Amperage (A) 10
Motor 1 hp
Pad Size 12” x 18”
Power Cable 40’ 12-3 GA Gray
Rubber Jacketed
Orbits Per Minute 3600
Orbit Dia. 1/4 inch
Shipping Weight 125 lbs.
Noise (dBA) 74
Vibration (m/s/s) 11.2
Figure 2 Figure 1
Introduction & Machine Specifications
The OBS-18 or OBS-18DC can be used on a variety of surfaces. It is an ideal tool for wood flooring maintenance and restoration work.
It is also suitable for cleaning hard surfaces such as tile or Terrazzo.
Machine Transportation
To transport the machine, follow this procedure:
1. Unplug machine from wall outlet and wrap cord.
2. Raise and lock the handle to the upright position. To lock the handle,
pull up on the Handle Release Compression Lever. See figure 1.
3. Grasp the machine at the lifting sites and place in cargo area. See
figure 2.
WARNING: The machine is heavy (125 lbs./57kg). to avoid injury
or damage to the machine use a firm grip and proper
lifting technique. Get assistance if necessary.
4. Secure machine to prevent movement in cargo area.
PERSON #1 PERSON #2
