Revision :1.1
3
1. Introduction to AR-ES0892FL
AR-ES0892FL is a system product mainly for ticket control, navigation, advertising, fleet
managements applications. With fanless design & dust-proof, AR-ES0892FL can satisfy
the users requirements in any application environment. AR-ES0892FL has diverse
physical interface in the front panel, such as VGA port, audio output, 10/100 LAN
connectors, 6 USB Ports, DB-44 for 6 console ports, DVI port, power switch, external
switch jack and PCI slot In addition, the system provides the capacity for extending I/O
device by adding DRAM, CF card depending on users needs.
1.1 Discrimination (included Rubber Foot)
Description AR-ES0892FL
CPU Board AR-B1892 series
Dimensions 252Ч323Ч80 (mm)
1.2 Packing List
Description Q’ty
AR-ES0892FL 1
Power Cord 1
HDD Cable 1
Console Cable (1*DB44 to
5*DB9 adapter cable)
1
Mounting bracket 2
Mounting bracket
Screw
4
CD 1
Quick Guide (AR-B1892) 1
