Revision: 1.0
1 Introduction to AR-R8601
Acrosser's Rackmount Networking device AR-R8601 is a cost-effective and entry-level
solution, which is suitable for small office. Base on VIA CN700 with ULV Eden 1600MHz
CPU, the AR-R8601 general very low heat. We also put a quiet Fan to keep the low noise
which will not cause uncomfortable voice. By three 10/100 Lans, the AR-R8601 is sufficient
for the small business security hardware solution.
Key features:
1. VIA EDEN ULV 1600 CPU.
2. VIA CN700+8237R plus Chipsets.
3. DDRII memory support (667MHz).
4. 3 x 10/100LAN RTL8100C.
5. CF socket, SATA x 1, SATA power, USB x 2.
6. Console, VGA (pinhead), KB/MS (Pinhead).
7. Support PXE boot from LAN.
8. Compact size.
1.1 Specifications
Item Description
System AR-R8601
CPU Board AR-B8601E16
System
Dimensions
440*189.5*44(mm)
