PARTS LIST
This list contains replaceable parts used in
your fireplace. When ordering parts, follow
the instructions listed under Replacement
Parts on page 23 of this manual.
PARTS LIST
Models CGCFTP and CGCFTN
KEY PART NUMBER
NO. CGCFTP CGCFTN DESCRIPTION QTY.
1 102633-02 102633-02 Outer Casing Top 1
2 102624-02 102624-02 Outer Casing 1
3 099230-02 099230-02 Shoulder Screw 14
4 098304-01 098304-01 Screw, #10 x 3/8" 16
5 109824-05 109824-05 Burner 1
6 103209-01 103209-01 Louvered Door 1
7 102635-02 102635-02 Left and Right Side Front 2
8 M11084-26 M11084-26 Hex Head Screw, #10 x 3/8" 28
9 103209-05 103209-05 Top Louver 1
10 104281-02CK 104281-02CK Firebox Hood 1
11 102638-01 102638-01 Firebox Top 1
12 104286-01 104285-01 ODS/Pilot Assembly 1
13 ** ** Firebox Wrapper 1
14 099211-01 099211-01 Control Bracket Screw 2
15 103963-01 103963-01 Inlet Tube 1
16 102834-01 102834-01 Outlet Tube 1
17 101629-02 101629-02 Bushing 1
18 098303-02 098303-02 Regulator Screw 2
19 ** ** Outer Shell Base 1
20 102649-02 102649-02 Branch Support 1
21 099415-09 099415-10 Gas Regulator 1
22 102875-01 102875-01 Regulator Bracket 1
23 101381-01 101381-01 Valve Cover and Piezo 1
24 099387-11 099387-11 Pilot Tube 1
25 098271-06 098271-06 Ignitor Cable 1
26 107186-01 107186-02 Injector 1
27 101629-01 101629-01 Bushing 1
28 098249-01 098249-01 Nut, M5 2
29 098522-26 098522-23 Gas Valve 1
30 102639-01 102639-01 Baffle 1
31 101628-01 101628-01 Flexible Connector 1
32 102869-01 102869-01 Control Bracket 1
33 102731-01 102731-01 Control Shield 1
34 103295-03CK 103295-03CK Screen Assembly 1
35 107154-01 107154-01 Log Set 1
36 104313-01 104313-01 Hinge, Right 1
37 104313-02 104313-02 Hinge, Left 1
38 M10908-2 M10908-2 Hinge Screws 4
39 103734-01 103734-01 Burner Support 2
40 097809-03 097809-03 3/8" NPT x 3/8" Flare Brass Fitting 1
41 101006-02 101006-02 Bracket, Pilot 1
42 098304-03 098304-03 Screw, #8 x 3/8" 4
43
___
107634-02 NG Conversion Plate 1
44 M10908-75 M10908-75 Hex wsr head tapping screw 1
PARTS AVAILABLE — NOT SHOWN
101054-01 101054-01 Lighting Instructions Plate 1
100563-01 100563-01 Warning Plate 1
103470-01 103470-01 Hardware Package 1
** Part not available for field replacement.
