Acrosser AR-N6000 - Manual (Page 4)

Revision: 1.1
1. Introduction to AR-N6000
Acrosser's Microbox Networking device AR-N6000 is a small, cost-effective and entry-level
solution, which is suitable for small office. Base on Intel ATOM D410 (single core & 512K cache) or
D510 (dual cores & 1M cache) 1.66GHz CPU, the AR-N6000 consumes very low power to save
the total costs. We also put a quiet fan to keep the low noise, which will not cause uncomfortable
voice. By four 10/100/1000Mbps LANs, the AR-N6000 is sufficient for the small business security
hardware solution.
Key features:
1. Intel ATOM D410 or D510 CPU
2. Intel ICH8M Chipsets.
3. DDRII 667/800 SO-DIMM x 1, up to 2GB memory
4. Intel 82574L 10/100/1000Mbps x 4
5. For N6000D51 system, LAN1 and LAN2 support bypass feature
6. CF socket, 2.5” HDD bay x 1, SATA II interface with power x 2
7. Console, VGA (pinhead), USB 2.0 x 4 (2 x connectors, 2 x pin head)
8. Support boot from LAN, console redirection
9. Support mini-PCI for feature expansion
10. Compact size
1.1. Specifications
Item Description
System AR-N6000
CPU Board AR-N6000 series
System Dimensions 242Ч150.5Ч40 (mm)
1.2. Packing List
Description Q’ty
AR-N6000 system 1
Console Cable 1
Quick user manual 1
CD with Driver and Manual 1
Power adapter 1
SATA cable 1
SATA power cable 1
USA or Europe or Japan or UK power cord 1
4
