9
Model 3VH22
Dayton Operating Instructions and Parts Manual
Repair Parts List
Reference
Number
Description Part No. Quantity
Use only original repair parts. This heater must use design-specific parts. Do not substitute or use
generic parts. Improper repair parts could cause serious or fatal injuries. This will also protect your
warranty coverage for parts replaced under warranty.
3VH22
(/\) Not shown.
(†) Accessories.
(*) Total hose length should not exceed 20 feet from tank/cylinder.
(**) Not a field replaceable part.
1 Top and Shell Assembly ** 1
2 Burner Assembly 103929-01 1
3 Ignitor Electrode 103904-01 1
4 Nozzle 103032-01 1
5 Base 103031-01 1
6 Stealth Knob 103036-01 1
7 Piezo Ignitor 102445-01 1
8 Thermocouple Kit 099236-01 1
9 Thermocouple Bracket 103854-01 1
10 Nozzle Locator 103037-01 1
11 Valve Assembly 103930-01 1
12 Cap Sleeve 078978-03 1
/\ Tradename Decal (3VH22) 099154-04 1
/\ Information Decal 099681-04 1
/\ Operation Decal 099683-02 1
/\ Regulator & Hose Assembly LPA3110 1
† Regulator LPA2160 1
† POL Connector LPA4020 1
† *10' Hose LPA1000 1
