© 2006 Directed Electronics - all rights reserved 1 19 9
T TY YP PIIC CA AL L C CO ON NN NE EC CT TIIO ON N D DIIA AG GR RA AM M
The diagram below shows typical types of connections.
FFuussee R Reeppllaacceem meenntt
Should the blade type 10-amp fuse in the inverter fuse socket blow,
remove the plastic cover and replace with the spare fuse provided or
equivalent. Determine the cause of the problem and remedy before
attempting to use the unit again.
AC PLUG TO INVERTER
AC POWER SOCKET
FOR GAME CONSOLE OR
OTHER DEVICE
POWER ON/OFF SWITCH
AUDIO AND VIDEO
RCA PHONE CONNECTIONS
FROM: GAME CONSOLE,
OR
PMP3520,
OR DMP040/070
AUDIO AND VIDEO
CABLES FROM GAME
PLATE TO AN A/V
SWITCH BOX OR
AUXILARY INPUT ON
A VIDEO SCREEN
OFF ON
VIDEO GAME
110V AC VIDEO
R
AUDIO
L
