PARTs lIsT
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 21 of this manual.
KEY
NO. PART NO.
DESCRIPTION QTY.
1 111435-01 Electronic Ignitor • • • • 1
10767-01 Front Panel • • 1
107675-01 Front Panel • • 1
3 103476-01 Grill Guard • • 1
103476-0 Grill Guard • • 1
4 05-11 Thermostat Gas Valve • 1
05-1 Thermostat Gas Valve • 1
05-13 Thermostat Gas Valve • 1
05- Thermostat Gas Valve • 1
5 1041-01 Bottom Glass Retainer • • 1
1041-0 Bottom Glass Retainer • • 1
6 060-0 Glass Panel • • 1
060-10 Glass Panel • • 1
7 ** Cabinet • • • • 1
1074-14 Deflector Assembly • • 1
1074-15 Deflector Assembly • • 1
071-11 Ignitor Cable • • • • 1
10 04-01 Nut, M5 • • • •
11 11003-01 ODS/Pilot Assembly • • 1
11003-0 ODS/Pilot Assembly • • 1
1 103446-0 Burner • • 1
103447-06 Burner • • 1
13 037-03 Pilot Tube • • • • 1
14 10345-05 Injector • 1
10345-06 Injector • 1
10345-0 Injector • 1
10345-07 Injector • 1
15 0066-0 Mounting Bracket • • • • 1
16 0415-17 Pressure Regulator • • 1
0415-1 Pressure Regulator • • 1
17 NJF C Hex Nut • • • • 1
1 10355-0 Outlet (Burner) Tubing • • • • 1
1 10356-0 Inlet Tubing • • • • 1
0 10303-03 Baffle • • 1
10303-04 Baffle • • 1
PARTS AvAILABLE — NOT SHOWN
10064-03 Hardware Assembly • • • • 1
105345-01 Cable Tie • • • • 1
107-01 Control Position Label • • • • 1
1043-01 Lighting Instruction Plate • • • • 1
GA4550 Base Kit • • • • 1
11016-01 Thermocouple Kit • • • • 1
** Not a field replaceable part.
VN20BT
A
VP20BT
A
VN30BT
A
VP30BT
A
